An orthogonal drawing of a wi-fi router is shown. Construct a freehand pictorial sketch of the wi-fi router as viewed in the direction of the arrow. (3 marks) --- 0 WORK AREA LINES (style=blank) --- \begin{array} {|l|} Answers could include: → Oblique view in the direction of the arrow → Perspective view in the direction of the arrow → Planometric view in the direction of the arrow. Answers could include: → Oblique view in the direction of the arrow → Perspective view in the direction of the arrow → Planometric view in the direction of the arrow.
\hline
\ \qquad \qquad \qquad \qquad \qquad \qquad \qquad \qquad \qquad \qquad \qquad \qquad \qquad \qquad \qquad \qquad \qquad \\
\ \\
\ \\
\ \\
\ \\
\ \\
\ \\
\ \\
\ \\
\ \\
\ \\
\ \\
\ \\
\ \\
\hline
\end{array}
ENGINEERING, TE 2020 HSC 27b
An orthographic drawing of a toggle switch is shown.
Produce a pictorial drawing of the toggle switch when viewed from the direction indicated by arrow A. (6 marks)
Use a scale of 2:1.
--- 12 WORK AREA LINES (style=blank) ---
Show Answers Only
Notes on this drawing:
→ Ensure correct scale of 2:1 is used
→ Ensure drawing is completed from the correct viewing direction
→ Drawing must be isometric as indicated by viewing direction
→ Do not show hidden detail or centrelines on pictorial drawing
→ Do not show dimensions unless explicitly asked
→ There is not a specific standard for drawing pictorial threads, show some working/attempt to show that a thread is present
Show Worked Solution
Notes on this drawing:
→ Ensure correct scale of 2:1 is used
→ Ensure drawing is completed from the correct viewing direction
→ Drawing must be isometric as indicated by viewing direction
→ Do not show hidden detail or centrelines on pictorial drawing
→ Do not show dimensions unless explicitly asked
→ There is not a specific standard for drawing pictorial threads, show some working/attempt to show that a thread is present
Mean mark 53%.
ENGINEERING, TE 2022 HSC 22d
An orthogonal view of a smart watch is shown.
Construct a freehand pictorial sketch of the smart watch as viewed in the direction of the arrow. (3 marks)
--- 6 WORK AREA LINES (style=blank) ---
Show Answers Only
Notes on this drawing:
→ Ensure correct viewing direction
→ Freehand sketch does not require instruments
→ Do not dimension or show hidden detail
→ Provide basic shape and important features with relatively straight lines
→ Ensure correct scale is used
Show Worked Solution
Notes on this drawing:
→ Ensure correct viewing direction
→ Freehand sketch does not require instruments
→ Do not dimension or show hidden detail
→ Provide basic shape and important features with relatively straight lines
→ Ensure correct scale is used
